This 4 channel 960H security system has been equipped with completely new features. Innovative QR-Code scan connectivity allows you to quickly and easily connect to your smartphone, tablet, or PC. The DVR offers 960H (960x480) real-time recording on all 4 channels at 30fps. Coupled with 600TVL high-resolution cameras, this system produces the clearer Analog surveillance image with more accurate color, all while maintaining image integrity.
NOTE: THE NEW VERSION OF THIS DVR NO LONGER INCLUDES AUDIO INPUTS

|
ZMD-DT-SIN4
| |
|---|---|
| Video and Audio Input | |
| Analog Video | 4-CH BNC |
| Audio | 4-CH RCA |
| Video and Audio Output | |
|---|---|
| VGA | 1-CH, 1920x1080@60HzÛ1280x1024@60HzÛ1024x768@60Hz |
| CVBS | 1-CH BNC, PAL: 704x576, NTSC: 704x480 |
| Audio | 1-CH BNC |
| Video and Audio Codec | |
|---|---|
| Video Compression | H.264 |
| Audio compression | G.711 |
| Frame Rate | NTSC:30fps, PAL:25fps |
| Multiple stream | Yes |
| Video resolution | 960H, D1, HD1,CIF |
| System | |
|---|---|
| Application support | IE Viewer / Live Monitoring / Parameter Setting / Recording/ Playback/ Mobile / Alarm Function |
| Recording Management | |
|---|---|
| Sync Playback | 4-CH |
| Playback Function | Fast forward / Rewind /Slow play/Digital Zoom |
| Record mode | Normal Recording / Intelligent Recording / Motion Detected Recording / External Alarm Triggered Recording |
| Backup | USB devices |
| Hard Disk Driver | |
|---|---|
| Interface type | 1 SATA (3.5") |
| Capacity | Up to 2TB |
| Network | |
|---|---|
| Network interface | 1 RJ45 10/100M |
| Protocol support | TCP/IP, UDP, DNS / DDNS, SMTP, UPNP, DHCP, HTTP, P2P.etc. |
| Smart device | iOS 6 up, Android 2.3 up |
| Video Detection and Alarm | |
|---|---|
| Motion detection | Yes |
| Auxiliary Interface | |
|---|---|
| Reset button | Yes |
| USB interface | 3 USB 2.0 (1 Rear) |
| Serial Interface | RS-485 (PTZ Control) |
| General | |
|---|---|
| Power supply | DC12V, 3A |
| Power consumption | <12W(Without hard disks) |
| Operating temperature | 32°F~122°F / 0 °C to 50 °C |
| Dimensions | 11.4in (W) x 9.1in (D) x 1.7in (H) / 290mm (W) x 230mm (D) x 42mm (H) |
| Weight | 2.38lbs |
| Language | 11 languages |
|
ZMD-CCH-BBS23NM - 600TVL IR Bullet Camera
| ||
|---|---|---|
| Image Sensor | 1/4" Color CMOS | |
| TV System | NTSC / PAL | |
| Horizontal Resolution | 600 TV-Lines | |
| Lens | 3.6mm | |
| Number of IR LEDs | 24 PCS | |
| Infrared Illumination (Night Vision) | up to 80ft (20~25m) | |
| Minimum Illumination | 0.1Lux(IR LED On) | |
| S/ N Ratio | ≥ 48dB | |
| Video Output | 1.0Vp-p, 75ohms (BNC) | |
| Weatherproof | Yes | |
| Operating Temperature | 14°F~122°F / -10°C ~50°C | |
| Power | 12V DC | |
| Power Consumption | IR on Max 150mA | |
| Dimensions (W x D x H) | 3.3" x 2.5" x 2.6" | |
| Gross Weight | 0.33 lbs | |
| Material | Metal Shell | |
What is Included
(1) ZMD-DT-SIN4 4 Channel 960H DVR
